1. Electrical Specifications
Type
Autotune
   Frequency Band
851-869 MHz
   Number of Channels
4
   Channel Bandwidth
25 KHz
   Minimum Channel Spacing
250 KHz
   Insertion Loss (Max.) per Channel
3.0dB
   Input Return Loss (Min.)
19dB
   Output Return Loss (Min.)
8.5dB
   Isolation, Tx-Tx (Min.)
60dB
   Isolation, Ant-Tx (Min.)
50dB
   Input Power/Channel Range
75W
   Reflected Power (Max.) Allowable from Ant.
75W

2. Mechanical Specifications
Type
Autotune
   Dimension(W*H*D)
277.1 * 282.8 * 246.0
   Connectors - Input
N-Female
   Connectors - Output
N-Female

3. Environmental Specifications

Type
Autotune
   Temperature Range
-20 ~ +55กษ
